SRS1249-DR3CH Auto Hot Stamping Machine 4 Stations 3 Colors High Durability
تفاصيل المنتج:
| مكان المنشأ: | الصين |
| اسم العلامة التجارية: | Senny |
| إصدار الشهادات: | CE SGS |
| رقم الموديل: | SRS1249-DR3CH |
شروط الدفع والشحن:
| الحد الأدنى لكمية: | 1pc |
|---|---|
| الأسعار: | negotiable |
| تفاصيل التغليف: | حزمة الخشب الرقائقي |
| وقت التسليم: | شهر واحد |
| شروط الدفع: | T/T ، L/C. |
| القدرة على العرض: | 10pcs /شهر |
|
معلومات تفصيلية |
|||
| لون الطباعة: | 3 ألوان | محطة: | 4 محطات |
|---|---|---|---|
| طباعة المتانة: | متانة عالية | حالة: | جديد |
| ضمان: | 1 سنة | خدمة بعد البيع: | فيديو أو عبر الإنترنت |
| وقت التسليم: | 45 يوم | شروط الدفع: | ر/ر |
| إصدار الشهادات: | CE SGS | تفاصيل الحزمة: | حزمة الخشب الرقائقي |
| خدمات بعد البيع: | فيديو أو عبر الإنترنت | ||
| إبراز: | auto hot stamping machine for rubber tubes,professional cylindrical container stamping machine,industrial hot stamping machine with warranty,professional cylindrical container stamping machine,industrial hot stamping machine with warranty |
||
منتوج وصف
Professional SRS1249-DR3CH Auto Hot Stamping Machine for Rubber Tubes Cylindrical Containers and More
Technical Specifications:
| Model | SRS1249-DR3CH |
| Printing stations | 4 (3 printing colors and 1 hot stamping color) |
| Printing speed | Up to 45pcs/min |
| Max. printing area | L250mm X W160mm |
| Product height | 250mm |
| Air presser | 6-7 bar |
| Power | 380V 50/60HZ |
Application:
This equipment is a multifunctional rotary multi-color screen printing machine with flexible configuration. It can be equipped with a hot stamping device according to production needs, enabling the seamless integration of screen printing and hot stamping processes.
It has a wide range of applications, and is particularly adept at printing patterns and characters on the surface of various cylindrical or cylindrical-like products, including round plastic bottle caps (such as those for beverage bottles and sauce bottles), glass tubes (like essence glass tubes in cosmetics and medical glass reagent tubes), wine bottle caps (covering metal or plastic caps for various wine bottles such as white wine and red wine), tubular products (e.g., toothpaste tubes, ointment hoses), lighter casings, as well as rubber tubes, lipstick casings, etc.
In terms of performance, it boasts several advantages: the operation process is optimized with a simple and intuitive interface, allowing even new operators to get started quickly; it adopts a high-precision positioning system to ensure minimal error in the printing position of patterns and characters on the product surface, achieving a high degree of; it features a high level of automation, enabling continuous operation from feeding, printing to discharging, significantly reducing manual intervention; and it has a fast printing speed, which can efficiently meet the needs of mass production and save time costs in the production process.
Features:
1. The machine can be designed as press station, plasma treatment system structure.
2. Innovative double-jig transmission system is very smooth when passing bottles, easy to change between different types of products and easy to operate.
3. Adopting PLC control and touch screen display, equipped with all kinds of monitoring system to ensure the stability and safety of the machine when running at high speed.
4. According to the product characteristics, the machine can be equipped with automatic loading and unloading, positioning, no bottle no printing and other functions.
5. All parts are from Germany, USA and Japan to ensure the machine quality and printing stability.
6. Support three languages: Chinese, English and Spanish.
7. Machine can be customized according to special products.
Printing samples
About us:
SENNY PRINTING EQUIPMENT CO.,LTD was established in the year 2004, it is specialized in designing and manufacturing precise automatic screen printing machines, stick labler machines, hot stamping machines and auxiliary equipments. Meanwhile, they can design any kinds of automatic printing machines according to customers' requirements.
SENNY has very good designers. The founder of SENNY was engaged in designing and developing screen printing machines early from the year 1994, and he got many achievements: he designed the first automatic screen printing machine; automatic screen printing machine for big iron pails; four colors sereen printing machine for big oil kettles; automatic screen printing machines controlled by module independently for bottles; automatic screen printing machine for pails from 10L 1o 20L(3colors and 7colors) and so on so forth.
In order to improve our products, SENNY adopts the advantages of the similar products in or abroad, and we also take customers' comments and suggestions into consideration. With the innovation and improvement for many years, the products produced by SENNY now are in a leading position in the domestic markets. And it also sales well all around the world.
With the mission“Excellence,Creation,Sincerity,Quality!”,SENNY insists on providing high--quality products and services, dedicating to exploring the new markets and seeking for mutual benefit and win-win state with our customers.
Senny Printing Equipment Co., Ltd insists in treating people with honesty and sincerity, and we believe this is the basis of our cooperation. We always put innovation in priority and continuously develop new products to satisfy our customer.
